Feature of Sintered SmCo:
The best temperature characteristics in the rare-earth magnet family
Manufactured by powder metallurgical process involving the sintering of powder under vacuum.
Both grades of SmCo5 and Sm2Co17, commonly referred to as 1:5 and 2:17 material are available.
Good corrosion resistance and no special surface treatment required excellent for compact designs where high working temperature is a major concern.
Grinding and slicing operations possible
Application:
applied to various electric motors, instruments, sensors, detectors, radar, and other high-tech equipment.

Magnetic property parameters of Sintered Sm2co17

Grade Br Hcb Hcj BHmax Tc  Tw (Br) (Hcj)
Max Typ Min Min Min Max Typ Min
[T] [T] [T] [kA/m] [kA/m] [kJ/m3] [] [] [%/] [%/]
[KGs] [KGs] [KGs] [KOe] [KOe] [MGOe]
RE2Co17 119/143 SmCo16 0.85 0.83 0.81 620 1433 143 127 119 820 350 -0.03 -0.2
8.5 8.3 8.1 7.8 18 18 16 15
RE2Co17 135/143 SmCo18 0.89 0.87 0.84 645 1433 159 143 135 820 350 -0.03 -0.2
8.9 8.7 8.4 8.1 18 20 18 17
RE2Co17 151/143 SmCo20 0.94 0.92 0.89 680 1433 175 159 151 820 350 -0.03 -0.2
9.4 9.2 8.9 8.5 18 22 20 19
RE2Co17 159/199 SmCo22H 0.98 0.95 0.93 710 1990 183 167 159 820 350 -0.03 -0.2
9.8 9.5 9.3 8.9 25 23 21 20
RE2Co17 159/143 SmCo22 0.98 0.95 0.93 710 1433 183 167 159 820 350 -0.03 -0.2
9.8 9.5 9.3 8.9 18 23 21 20
RE2Co17 175/199 SmCo24H 1.02 0.99 0.96 724 1990 199 183 175 820 350 -0.03 -0.2
10.2 9.9 9.6 9.1 25 25 23 22
RE2Co17 175/143 SmCo24 1.02 0.99 0.96 724 1433 199 183 175 820 350 -0.03 -0.2
10.2 9.9 9.6 9.1 18 25 23 22
RE2Co17 191/199 SmCo26H 1.06 1.04 1.02 750 1990 215 199 191 820 350 -0.03 -0.2
10.6 10.4 10.2 9.4 25 27 25 24
RE2Co17 191/143 SmCo26 1.06 1.04 1.02 750 1433 215 199 191 820 350 -0.03 -0.2
10.6 10.4 10.2 9.4 18 27 25 24
RE2Co17 191/80 SmCo26M 1.06 1.04 1.02 637-796 796-1273 215 199 191 820 250 -0.03 -0.2
10.6 10.4 10.2 8.0-10  10-16 27 25 24
RE2Co17 191/44 SmCo 26L 1.06 1.04 1.02 413-716 438-796 215 199 191 820 250 -0.03 -0.2
10.6 10.4 10.2 5.2-9 5.5-10 27 25 24
RE2Co17 207/199 SmCo28H 1.08 1.07 1.04 756 1990 231 215 207 820 350 -0.03 -0.2
10.8 10.7 10.4 9.5 25 29 27 26
RE2Co17 207/143 SmCo28 1.08 1.07 1.04 756 1433 231 215 207 820 350 -0.03 -0.2
10.8 10.7 10.4 9.5 18 29 27 26
RE2Co17 207/80 SmCo28M 1.08 1.07 1.04 660-796 796-1273 231 215 207 820 250 -0.03 -0.2
10.8 10.7 10.4 8.3-10  10-16 29 27 26
RE2Co17 207/44 SmCo28L 1.08 1.07 1.04 413-716 438-796 231 215 207 820 250 -0.03 -0.2
10.8 10.7 10.4 5.2-9 5.5-10 29 27 26
RE2Co17 222/199 SmCo30H 1.11 1.1 1.08 788 1990 247 231 222 820 350 -0.035 -0.2
11.1 11 10.8 9.9 25 31 29 28
RE2Co17 222/143 SmCo30 1.11 1.1 1.08 788 1433 247 231 222 820 350 -0.035 -0.2
11.1 11.0  10.8 9.9 18 31 29 28
RE2Co17 222/80 SmCo30M 1.12 1.1 1.08 676-812 796-1273 247 231 222 820 250 -0.035 -0.2
11.2 11.0  10.8 8.5-10.2  10-16 31 29 28
RE2Co17 222/44 SmCo30L 1.13 1.1 1.08 413-716 438-796 247 231 222 820 250 -0.035 -0.2
11.3 11.0  10.8 5.2-9 5.5-10 31 29 28
RE2Co17 239/143 SmCo32 1.14 1.12 1.1 796 1433 263 247 231 820 350 -0.035 -0.2
11.4 11.2 11.0  10 18 33 31 29
RE2Co17 239/80 SmCo32M 1.15 1.12 1.1 676-844 796-1273 263 247 231 820 250 -0.035 -0.2
11.5 11.2 11.0  8.5-10.6 10-16 33 31 29
RE2Co17 239/44 SmCo32L 1.15 1.12 1.1 413-716 438-796 263 247 231 820 250 -0.035 -0.2
11.5 11.2 11.0  5.2-9 5.5-10 33 31 29
RE2Co17 175/119 SmCo24LT 1.04 1.0  0.98 676 1194 207 191 175 850 350 -0.01 -0.15
10.4 10 9.8 8.5 15 26 24 22
RE2Co17 191/119 SmCo26LT 1.08 1.05 1.03 676 1194 222 207 191 850 350 -0.01 -0.15
10.8 10.5 10.3 8.5 15 28 26 24

Note1:Curie temperature and temperature coefficient are for reference,but not as inspection base.

Note2:If the customer has a special requirement on the magnetic properties, the technical contract agreed by the supply and demand both sides decides.

Note3:Sintered SmCo permanent magnets have a greater brittleness and are lack of ductility, so they should not be used as a structural element design.





Our group has a real anbition to develop and produce a range of complex magnetic assemmblies tailored to our customers requirements. These will be used in a wide range of applications from motors to sensors and a host of
other instruments.Examples are:

Magnetic Limpets:
Used as holding/retaining tools for machine shops doing turning, milling, grinding and cutting operations...
Magnetic chip collectors: widely used in the fields such as food, medicine, and textile, chemistry and sewage treat-
ment industries.
Magnetic Chucks & Lifting Devices:
Elegantly designed equipment conceived to facilitate the safe and secure handling of heavy industrial parts


Features of Sintered NdFeB
The most powerful magnets commercially available
Manufactured by a powder metallurgical process involving the sintering of powder compacts under vacuum
Grinding and slicing possible
Very reactive with moisture and oxygen
A variety of Coatings can applied depending on the environment of the application
Applications:
Various types of electric motors, engineering equipment, medical equipment, audio apparatus and household appliances


Magnetic property parameters of cast NdFeB
Material Grade Remanence (Min.) Intrinsic coercivity(Min.) Coercivity(Min.) Max. Magnetic Energy Product Density Temp. coefficient Curie Temp. Max.Operation temp.
Br Hcj Hcb BHmax D Br Hcj Tc Tw
(L/D0.7)
Gs mT Oe KA/m Oe KA/m MGOe KJ/m3 g/cm3 %/  %/
N30 10800~11300 1080~1130 12000 955 10000 796 28~31 223~247 7.45  -0.12 -0.6 310 80
N33 11300~11700 1130~1170 12000 955 10500 836 31~34 247~271 7.45  -0.12 -0.6 310 80
N35 11700~12200 1170~1220 12000 955 10900 868 33~36 263~287 7.45  -0.12 -0.6 310 80
N38 12200~12500 1220~1250 12000 955 11300 899 36~39 287~310 7.50  -0.12 -0.6 320 80
N40 12500~12800 1250~1280 12000 955 11600 923 38~41 302~326 7.50  -0.12 -0.6 320 80
N42 12800~13300 1280~1330 12000 955 11600 923 40~43 318~342 7.50  -0.12 -0.6 320 80
N45 13300~13700 1330~1370 12000 955 11000 876 43~46 342~366 7.50  -0.12 -0.6 320 80
N48 13700~14200 1370~1420 12000 955 11200 892 46~49 366~390 7.50  -0.12 -0.6 320 80
N50 13900~14400 1390~1440 11000 876 10500 836 47~51 374~406 7.55  -0.12 -0.6 320 80
N52 14200~14700 1420~1470 11000 876 10500 836 49~53 390~422 7.55  -0.12 -0.6 320 80
N30M 10800~11300 1080~1130 14000 1114 10000 796 28~31 223~247 7.50  -0.12 -0.6 320 100
N33M 11300~11700 1130~1170 14000 1114 10500 836 31~34 247~271 7.50  -0.12 -0.6100
N35M 11700~12200 1170~1220 14000 1114 10900 868 33~36 263~287 7.50  -0.12 -0.6 320 100
N38M 12200~12500 1220~1250 14000 1114 11300 899 36~39 287~310 7.50  -0.12 -0.6 320 100
N40M 12500~12800 1250~1300 14000 1114 11600 923 38~41 302~326 7.50  -0.12 -0.6 320 100
N42M 12800~13300 1280~1320 14000 1114 12000 955 40~43 318~342 7.50  -0.12 -0.6 320 100
N45M 13300~13700 1330~1370 14000 1114 12500 995 43~46 342~366 7.50  -0.12 -0.6 320 100
N48M 13600~14200 1360~1420 14000 1114 12800 1019 45~49 358~390 7.55  -0.12 -0.6 320 100
N50M 13900~14400 1390~1440 14000 1114 13000 1035 47~51 374~406 7.55  -0.12 -0.6 320 100
N52M 14200~14, 700 1420~1470 13000 1035 12500 995 49~53 390~422 7.55  -0.12 -0.6 320 100
N30H 10800~11300 1080~1130 17000 1353 10000 796 28~31 223~247 7.50  -0.12 -0.6 320 120
N33H 11300~11700 1130~1170 17000 1353 10500 836 31~34 247~271 7.50  -0.11 -0.58 320 120
N35H 11700~12200 1170~1220 17000 1353 10900 868 33~36 263~287 7.50  -0.11 -0.58 320 120
N38H 12200~12500 1220~1250 17000 1353 11300 899 36~39 287~310 7.50  -0.11 -0.58 320 120
N40H 12500~12800 1250~1280 17000 1353 11600 923 38~41 302~326 7.55  -0.12 -0.6 320 120
N42H 12800~13300 1280~1330 17000 1353 12000 955 40~43 318~342 7.55  -0.12 -0.6 320 120
N45H 13300~13700 1330~1370 17000 1353963 43~46 342~366 7.55  -0.12 -0.6 320 120
N48H 13600~14200 1360~1420 17000 1353 12900 1027 45~49 358~390 7.60  -0.12 -0.6 320 120
N50H 13900~14400 1390~1440 16000 1274 13000 1035 47~51 374~406 7.60  -0.12 -0.6 320 120
N30SH 10800~11300 1080~1130 20000 1592 10100 804 28~31 223~247 7.50  -0.11 -0.55 320 150
N33SH 11300~11700 1130~1170 20000 1592 10600 844 31~34 247~271 7.50  -0.11 -0.55 320 150
N35SH 11700~12200 1170~1220 20000 1592 11000 876 33~36 263~287 7.55  -0.11 -0.55 320 150
N38SH 12200~12500 1220~1250 20000 1592 11400 907 36~39 287~310 7.55  -0.11 -0.55 320 150
N40SH 12500~12800 1250~1280 20000 1592 11800 939 , 38~41 302~326 7.55  -0.11 -0.55 320 150
N42SH 12800~13200 1280~1320 20000 1592 12200 971 40~43 318~342 7.55  -0.11 -0.55 320 150
N45SH 13200~13700 1320~1370 20000 1592 12300 979 43~46 342~366 7.60  -0.11 -0.55 320 150
N48SH 13600~14200 1360~1420 19000 1512 12500 995 45~49 358~390 7.60  -0.11 -0.55 320 150
N28UH 10200~10800 1020~1080 25000 1990 9600 764 26~29 207~231 7.50  -0.1 -0.51 320 180
N30UH 10800~11300 1080~1130 25000 1990 10200 812 28~31 223~247 7.50  -0.1 -0.51 320 180
N33UH 11300~11700 1130~1170 25000 1990 10700 852 31~34 247~271 7.55  -0.1 -0.51 320 180
N35UH 11700~12200 1170~1220 25000 1990 10800 860 33~36 263~287 7.55  -0.1 -0.51 320 180
N38UH 12200~12500 1220~1250 25000 1990 11000 876 36~39 287~310 7.60  -0.1 -0.48 320 180
N40UH 12500~12800 1250~1280 25000 1990 11500 915 38~41 302~326 7.60  -0.1 -0.48 320 180
N42UH 12700~13200 1270~1320 24000 1910 12200 971 39~43 310~342 7.60  -0.1 -0.48 320 180
N28EH 10400~10900 1040~1090 30000 2388 9800 780 26~29 207~231 7.60  -0.09 -0.48 320 200
N30EH 10800~11300 1080~1130 30000 2388 10200 812 28~31 223~247 7.60  -0.09 -0.48 320 200
N33EH 11300~11700 1130~1170 30000 2388 10300 820 31~34 247~271 7.60  -0.09 -0.48 320 200
N35EH 11700~12200 1170~1220 30000 2388 10500 836 33~36 263~287 7.60  -0.09 -0.48 320 200
N, 38EH 12000~12500 1200~1250 30000 2388 11500 915 35~39 279~310 7.60  -0.09 -0.48 320 200
N28AH 10200~10900 1020~1090 34000 2706 9800 780 25~29 199~231 7.60  -0.09 -0.45 320 240
N30AH 10700~11300 1070~1130 34000 2706 10200 812 27~31 215~247 7.60  -0.09 -0.45 320 240
N33AH 11100~11700 1110~1170 34000 2706 10300 820 30~34 239~271 7.60  -0.09 -0.45 320 240
N35AH 11700~12200 1170~1220 34000 2706 10500 836 32~36 255~287 7.60  -0.09 -0.45 320 240
N38AH 12000~12500 1170~1220 34000 2706 11500 915 35~39 279~310 7.60  -0.09 -0.45 320 240

NoteThe datas in the table are the test results at the temperature of 20 .
